Industrial UV Flatbed Printer for Large Size 60*90cm Operating System Window7/8/9

Name: Industrial UV Flatbed Printer for Large Size 6090cm Operating System Window789
Brand: Big-color
Price: 7 USD

Wholesale Industrial UV Flatbed Printer for Large Size 60*90cm Operating System Window7/8/9 from china suppliers

Type : Inkjet Printer

Print Dimension : 90*60cm

Applicable Industries : Building Material Shops, Restaurant, Retail, Food Shop, Printing Shops, Food & Beverage Shops, Advertising Company

Condition : New

Plate Type : Flatbed Printer

Place of Origin : Anhui, China

Brand Name : Big-color

Use : Paper Printer, Label Printer, Card Printer, Tube Printer, Bill Printer, Cloths Printer

Automatic Grade : Automatic

Color & Page : Multicolor

Voltage : 220v/110v

Dimensions(L*W*H) : 2120*1500*1220mm

Weight : 380 KG

Warranty : 1 Year, 1 year

Ink Type : uv ink

Key Selling Points : High Productivity

Marketing Type : Ordinary Product

Machinery Test Report : Provided

Video outgoing-inspection : Provided

Warranty of core components : 13 months

After-sales Service Provided : Video technical support

Product name : UV Flatbed Printer

Printing material : Metal,ceramic,acrylic board,wood,leather and so on

Print speed : 6.5㎡/h

Operating system : Window7/8/9

Packaging Details : The normal package is stronger wooden box with metal structure inside(packaging size: 2300*1400*1500mm). If export to european countries,the wooden box will be fumigated.If container is too tighter,we will use PE film for packing or pack it according to cu

Price : $7,200.00/sets 1-9 sets

MOQ : 1 set

Contact Now

Product Description

Product Application

Big Color small size uv printer flatbed can print on roraty and flat material by one printer. It can print colors , white and varnish at same time.It also support on mirror printing and back printing which means it can work on all kinds of industry production.

SPECIFICATIONS FOR ZT-6090
Product Name	uv6090 flatbed printer
Model	ZT6090 uv printer
Printer head	3 pc TX800/4720/ 3200U1 head
Speed	7.5m2/h(Production mode) / 5.5m2/h(Precision mode) / 4.5m2/h(High precision mode)
Maximum Resolution	720*4320 dpi
Ink	4 color +white +varnish
Printing Type	Glass ,Acylic board,Wood,Board,Metal,Leather and so on
Connect port	USB3.0 High speed transfer port
Machine Dimension	1.51.61.38m
packing size	1.851.691.05m=3.282

Model No	Print head	Printing area	Printing height	Speed	Color
6090-dx8	3 pcs Epson DX8	600*900mm	250mm	4.5m²/h	CMYK+W+V
6090-dx9	3 pcs Epson xp600	600*900mm	250mm	4.5m²/h	CMYK+W+V
6090-4720/3200	3 pcs Epson 4720	600*900mm	250mm	7.5m²/h	CMYK+W+V

System:

Much more protessional and more stable than desktop modified printer. Control the color freely.

The front of printer.

The side of printer.

No based table type.

_{No based table type.}

LCD Touch Control Panel:

LED touch screen, more convenient operation

CNC aluminum beam & PTFE vacuum platform.

CNC alumimum beam is good material for good printing.The main function is to ensure the stability of the printing process

PTFE vaccum platbed will guarantee strong suction for printing material,Especially for light materials, ensure that it will not move during the printing process

Rotary & Mug cup Print Unit.

Both flatbed printing and rotary printing(for bottle and mugs)

Stronger CNC Machine Frame：

16 position adjustable position for vaccum table.

Auto Height Sensor：

It can automatically measure the printing height, saving a lot of labor and time for you.

Reliable Board System.

Two small fan is installed on the board to cool down the board card and prolong the service life of the board card.

Multi-function button：

Poweder machine control Unit: Powder drop speed, Powder shake speed, heater temperature adjustable.

Ink Alarming system & Ink Stiring system:

Powder drop speed, Powder shake speed, heater temperature adjustable.

Stainless steel capping station

Stainless steel capping station, corrosion resistance, long service life

Stronger Screw Bar on Yaxis:

The printing movement of the machine depends on the screw.We use many stable screw to guaranteed quality.

3pcs Big Water cooling Lamp.

Dual Fan Body Cooling System:

Different head optional for different request

3200 head:

higher head cost, but faster printing speed
it is fit for printing factory choose

DX8 head:

Lower head cost, but speed slower than 3200 head
it is fit for home work usage

Main Features

1) Not only can print on flatbed material but also can printer cylinders.

2) Automatic stirring system for white ink and lacking ink alarming system.

3) PTFE cellular flatform,durable and stable.

4) Carriage height could reach to 250mm ,and it can work on 3 heads by varnish+white+color or even 4 heads.

5) Support for multiple printing on same picture by one time,fit for most special production request .

6) Our Big color have focus on printer research manufacture for more than 10 yeas, we also work on OEM printing machine. so we could also give you best suggestion and solution for your printing request if you need.

CE Certifications

Sample

Wine bottle

leather

sheath

Phone case

Mug or cup

UV DTF FILM

DTF PRINTER for 30cm

A2/A3 uv flatbed printer

Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Product packaging

uv printer Packaging
size	1.851.691.05M=3.3CBM
weight	0.3T
Packaging Details	The normal package is wooden box. If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
